    Customized Size Plumbing Pipe Fittings , 6 / 4 Inch Pipe Plug Abrasive Resistance

    Ask Lasest Price
    Brand Name : kanaif
    Model Number : Malleable Iron Pipe Fitting Plug
    Certification : FM/UL
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 10000piece/week
    Delivery Time : 25-35days
    • Product Details
    • Company Profile

    Customized Size Plumbing Pipe Fittings , 6 / 4 Inch Pipe Plug Abrasive Resistance

    Malleable Iron Pipe Fitting Plugs High pressure Hexagon Plug

    MaterialMalleable iron
    StandardThread: ISO 7/1
    DimensionISO 49, DIN 2950,EN10242
    Chemical property(C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S% <0.2%)
    Physical propertyTensile strength>=350Mpa,Elongation>=10% Hardness<=150HB
    Testing pressure2.5Mpa
    Working pressure1.6Mpa
    TypeBeaded with ribs or banded with ribs
    Beaded without ribs or banded without ribs
    Round/square
    SurfaceGalvanized/ no galvanized
    ColorWhite/black
    ModelElbow, Tees, Crosses, Bends, Unions, Bushings, Lateral Braches, Sockets, Nipples, Hexagon/Round, Caps, Plugs, Locknuts, Flanges ,Side Outlet Tees, Side Outlet Elbows and etc
    ConnectionMale, Female
    ShapeEqual, Reducing
    CertificateBSI,ANAB,ISO9001,FM,UL
    ApplicationSuitable for pipe connect of steam, air, gas, oil and so on
    Buyer’s drawings or designs are available
    PackageCartons without pallet
    Cartons with pallet
    Double woven bags
    Or as buyer’s requirements
    Delivery detailsAccording to the quantities and specifications of each order
    Normal delivery time is from 30 to 45 days after receiving the deposit

    Malleable Iron Pipe Fitting Plugs High pressure Hexagon Plug


    • The quality ensuring of Malleable Iron Pipe Fitting Plug is controlled by full automatic product-lines of DISA Denmark ,SINTOKOGIO and DJAMF Japan.

    • The spectrometer of Oxford Instruments we bought for analyzing the quality of Malleable Iron Pipe Fitting Plug samples.
    • In order to improve material physical characteristics ,we set a higher heating value gas furnace to control the annealing process strictly .
    • The size of Malleable Iron Pipe Fitting Plug ranging from 1/8” to 6”.
    • Better toughness creates long using life.
    • No any and hole discovered on surface.Zinc thickness of hot galvanized products, is according to international standard strictly.
    • Thread diameter, parallelism, angle, tooth type have to be finely manufactured , Each union must pass the testing of plug gauge.
    • After tightness test,each socket can be ensured no leakage.

    Size excel of Malleable Iron Pipe Fitting Plug

    SizeInch1/81/43/81/23/4111/4
    mm681015202532
    Dim.
    (mm)
    A15.518.320.123.927.231.834.5
    SizeInch11/2221/2346
    mm40506580100150
    Dim.
    (mm)
    A36.939.7464964.571.5


    Customized Size Plumbing Pipe Fittings , 6 / 4 Inch Pipe Plug Abrasive Resistance
