Briefly discribe of our enterprise :
We are manufaturer of Beaded Equal 90 Degree Tees about 24 years,
we catch each opportunity to show our strength, and present it as
today, our enterprise group with advanced technology, equipment and
strong comprehensive strength,knows for its complete ranges of
products, large producing capacity,high quality, etc.
Sheet of Beaded Equal 90 Degree Tees
| Size | Inch | 1/8 | 1/4 | 3/8 | 1/2 | 3/4 | 1 | 11/4 | 11/2 |
| mm | 6 | 8 | 10 | 15 | 20 | 25 | 32 | 40 |
Dim.
(mm) | A | 17.5 | 20.6 | 24.1 | 28.5 | 33.3 | 38.1 | 44.5 | 49.3 |
| Size | Inch | 2 | 21/2 | 3 | 4 | 5 | 6 | 8 | |
| mm | 50 | 65 | 80 | 100 | 125 | 150 | 200 | |
Dim.
(mm) | A | 57.2 | 68.6 | 78.2 | 96.3 | 114.3 | 130.3 | 162 | |
Detail informations:
· Material: iron
· Technics:casing
· Surface treatment: Hot dipped galvanized and cold galvanized
· Connection:male&female
· Head Shape:equal
· Head Code:Round
· size:1/8"-8"
· Standard:ANSI, BS, DIN
· Packing:wooden cases or as cusdtomers' demands
· surfacetreatment:painting galvaized or as customers' demands
1. Tight test :
In order to guarantee nice sealing property, all of the products
must pass tight test before delivery
2. Strictly control :
Strictly control the size of the thread, to ensure accuracy
3. Processing technology :
For ensuring to control malleable iron tee pipe fittings, we use
the most advanced metallurgical and processing technology.
4. Material quality of Beaded Equal 90 Degree Tees:
cast iron samples are continuously analyzed by using spectroscopy
to conform the material quality
5. Annealing process :
Strictly control the annealing process, improve the physical
properties of the material
Technical parameters:
Material | iron |
| Standard | Thread: ISO 7/1 |
| Dimension | ISO 49, DIN 2950,EN10242 |
| Chemical property | (C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S%
<0.2%) |
| Physical property | Tensile strength>=350Mpa,Elongation>=10% Hardness<=150HB |
| Testing pressure | 2.5Mpa |
| Working pressure | 1.6Mpa |
Type | Beaded with ribs or banded with ribs |
| Beaded without ribs or banded without ribs |
| Round/square |
| Surface | Galvanized/ no galvanized |
| Color | White/black |
| Model | Elbow, Tees, Crosses, Bends, Unions, Bushings, Lateral Braches,
Sockets, Nipples, Hexagon/Round, Caps, Plugs, Locknuts, Flanges
,Side Outlet Tees, Side Outlet Elbows and etc |
| Connection | Male, Female |
| Shape | Equal, Reducing |
| Certificate | BSI,ANAB,ISO9001,FM,UL |
Application | Suitable for pipe connect of steam, air, gas, oil and so on |
| Buyer’s drawings or designs are available |
Package | Cartons without pallet |
| Cartons with pallet |
| Double woven bags |
| Or as buyer’s requirements |
Delivery details
| According to the quantities and specifications of each order |
| Normal delivery time is from 30 to 45 days after receiving the
deposit |
Black Malleable Hot Dipped and Cold Galvanized Beaded Equal 90
Degree Tees
